Function
STATYS Integrable is a fully integrated static transfer power unit for integration into a cabinet or a power distribution unit (PDU).
Supplied by two independent sources, STATYS Integrable increases the overall electrical infrastructure availability during abnormal events and programmed maintenance.
Advantages
Easy integration
- Pre-engineered mechanical and electrical connections for ease of integration into cabinets or PDUs.
- Installed simply by one operator with no special equipment required.
- STATYS Integrable is operated by any HMI via a single connection bus using Modbus protocol.
Unparalleled serviceability
- STATYS Integrable can be easily integrated or swapped with a new one without specific tools.
- Preventive maintenance is made quick by front-accessible components and drawer-mounted fans.
Best resiliency
- Full redundant internal design ensuring no single point of failure.
- Internal segregation between critical functions to prevent fault propagation.
- Load protection ensured even during an internal fault.
Robust design
- Compatible with all types of electrical infrastructure and applications.
- Fully rated SCR ensures no restriction to the continuation of the operation.
Applications
- Data center - Power availability for servers
Technical data
| Rating (A) | 200 | 400 | 600 | 800 | 1000 | 1200 |
| ELECTRICAL SPECIFICATIONS | |||||||
|---|---|---|---|---|---|---|---|
| Rated voltage | 208-220/380-415/480/600 V | ||||||
| Voltage tolerance | ± 10% (configurable) | ||||||
| Non-synchronized sources management | configurable up to ±180 | ||||||
| Frequency | 50 Hz or 60 Hz ± 5 Hz (configurable) | ||||||
| Number of phases | 3ph+N or 3ph (+ PE) | 3ph (+PE) | |||||
| Number of poles switching | 3 or 4-pole switching | 3 pole switching | |||||
| Maintenance bypass (cabinet version) | monitoring up to 6 breakers | ||||||
| Overload | 150% for 2 minutes - 110% for 60 minutes | ||||||
| Efficiency | 99% | ||||||
| Admissible power factor | no restrictions | ||||||
| ENVIRONMENT | |||||||
|---|---|---|---|---|---|---|---|
| Operating ambient temperature | 32-104 °F / 0-40 °C | ||||||
| Relative humidity | 95% | ||||||
| Maximum altitude | 3280 ft / 1000 m a.s.l. without derating | ||||||
| Acoustic level at 3.28 ft / 1m (ISO 3746) | ≤ 60 dBA | ||||||
| STANDARDS | |||||||
|---|---|---|---|---|---|---|---|
| Safety | UL 1008 S | ||||||
| EMC | C2 category IEC 62310-2, FCC part 15 | ||||||
Socomec services
Socomec offers comprehensive support to optimize the performance and longevity of your equipment. 400 experts and 250 engineers are mobilized to offer a complete service, from commissioning to end-of-life management of your equipment.
Platinum Warranty
Platinum Warranty improves standard factory coverage: contractual response times, priority hotline access and optional preventive maintenance.
