Function
BCT-Cs are current transformers that offer accurate measurement of currents up to 2400 A. BCT-C current transformers play a crucial role in billing applications and those that require state-of-the-art accuracy. Their level of accuracy ensures extremely reliable and true-to-life measurements.
Conformity to standards
IEC 61869-2
IEC 61010
Advantages
Exceptional accuracy
Accuracy Class 0.2S provides extremely high quality measurement, even at low loads. Socomec’s exclusive Class 0.2Smax accuracy class guarantees extremely accurate measurements from 0.2 to 120% In, with constant accuracy of 0.2% over the entire range..
Extended measuring range
BCT-C performance reduces the number of references needed in the field. A single BCT-C can cover a current range from 4 to 2400 A.
Easy to install
Several mounting options are available, enabling installation on a backplate, a DIN rail or directly on the bar or cable itself.
Infinitely customizable
The technical specifications are fully customizable, from rated current to the number of turns desired.
