Strong Points
Function
In addition to our automatic transfer switching solution, Socomec offers the option of ordering the switch separately. This enables users to order spares or to use Socomec switches with their own controllers.
Conformity to standards
UL 1008 CSA-C22.2 No.178.1-14 Guide WPWR File E506172
References
ATyS FT is available in 12 versions
| Item | Conformity to standard #1 | Rated current [A] | Number of poles | Control operator | Select |
|---|---|---|---|---|---|
| 96002026 | cULus 1008 | 260 | 2 | RTSE | |
| 96003026 | cULus 1008 | 260 | 3 | RTSE | |
| 96004026 | cULus 1008 | 260 | 4 | RTSE | |
| 96002040 | cULus 1008 | 400 | 2 | RTSE | |
| 96003040 | cULus 1008 | 400 | 3 | RTSE | |
| 96004040 | cULus 1008 | 400 | 4 | RTSE | |
| 96012026 | cULus 1008 | 260 | 2 | RTSE | |
| 96012040 | cULus 1008 | 400 | 2 | RTSE | |
| 96013010 | cULus 1008 | 100 | 3 | RTSE | |
| 96013020 | cULus 1008 | 200 | 3 | RTSE | |
| 96013026 | cULus 1008 | 260 | 3 | RTSE | |
| 96013040 | cULus 1008 | 400 | 3 | RTSE |
Advantages
Compatible with virtually any TSE controls
The ATyS is compatible with virtually any transfer switching control solution providing volt-free contacts. This allows the ATyS to be combined with most TSE controls available on the market and then used in automatic transfer switch applications.
Robust, reliable and high performing
Rated for emergency system and total system without derating, these switches also include high short-circuit rating with specific breakers or fuses up to 100 kA.
Safe manual handle
The ATyS FT ensures the safety of your maintenance personnel thanks to patented safety features. A transparent polycarbonate cover prohibits access to the manual handle, requiring deliberate action to open it. Once the cover is opened, the switch and the controller are electrically inhibited, preventing any unexpected transfer during maintenance. When using the main manual handle, the power switching characteristics are as reliable as when operated automatically, ensuring safe transfers in all cases.
Inspectable contacts
The ATyS FT is specifically designed to reduce the time it takes to inspect power contacts when utilizing the specific maintenance mode.
