Strong Points
Function
The WattNode delivers over 50 electrical measurements communicated using BACnet protocol over RS-485.
Designed as a universal, line-powered meter, the WattNode Wide-Range BACnet supports utility services from 100 to 600 VAC, single-phase or three-phase, wye or delta, with revenue-grade accuracy.
The WattNode includes fast power for export limiting, remote wiring error correction, potential transformer ratios for 4160 VAC and above and can be used with any low voltage CT (0.333 Vac output). The BACnet meter has been independently tested by the BACnet testing laboratories (BTL), and is BACnet certified.
Conformity to standards
UL 61010-1, CSA-C22.22, No. 61010-1 File E359088
California Energy Commission
BTL Listed
References
WattNode® BACnet is available in 1 version
| Item | Model | Application | Type | Communication protocols | Communication ports | Select |
|---|---|---|---|---|---|---|
| 48710200 | WND-WR-BN | Metering | Power Meter | BACnet MS/TP | RS485 |
Advantages
Revenue Grade Accuracy
- Meets ANSI C12.1-2014 & ANSI C12.20-2015.
- Class 0.5 accuracy (with Socomec ACTL CTs)
Low Voltage mV Sensors
- No shorting blocks are needed.
- Can safely be disconnected under load.
Compact & Flexible Design
Small form factor allows for easy installation in tight electrical panels.
Universal Voltage
Compatible with any utility service from 100-600 VAC, single or three-phase load, wye or delta.
Diagnostic LEDs
Confirms correct status of voltage and CT connections for reliable power and energy measurements.
Bi-Directional Metering
The WattNode measures the flow of electricity in both directions (import/export).
Applications
- Energy - Energy storage for grid services
- Industry - Power quality and power monitoring
- Building - Metering and sub-billing
