Strong Points
Function
The WattNode delivers over 50 electrical measurements via Modbus RTU (RS485) communication.
Designed as a universal, line-powered meter, the WattNode Wide Range supports utility services from 100 to 600 VAC, single-phase or three-phase, wye or delta, with revenue-grade accuracy.
The WattNode meter module is powered by 12-24 VAC or DC. The WattNode with Modbus communication features an expanded Modbus register map, including fast power for export limiting, remote wiring error correction, potential transformer ratios for 4160 VAC and above, and full SunSpec compliance.
Conformity to standards
UL 61010-1, CSA-C22.22, No. 61010-1 File E359088
SunSpec
California Energy Commission
BTL Listed
References
WattNode® Modbus is available in 2 versions
| Item | Model | Application | Type | Communication protocols | Communication ports | Select |
|---|---|---|---|---|---|---|
| 48710100 | WND-WR-MB-BA | Metering | Power Meter | Modbus RTU | RS485 | |
| 48710000 | WND-WR-MB | Metering | Power Meter | Modbus RTU | RS485 |
Advantages
Revenue Grade Accuracy
- Meets ANSI C12.1-2014 & ANSI C12.20-2015.
- Class 0.5 accuracy (with Socomec ACTL CTs)
Expanded Modbus Register Map
- Fast power for export limiting.
- Registers to correct wiring errors remotely.
- SunSpec compliance for solar and energy management (Modbus only).
Low Voltage mV Sensors
- No shorting blocks are needed.
- Can safely be disconnected under load.
Compact Design
Small form factor allows for easy installation in tight electrical panels.
Universal Voltage
Compatible with any utility service from 100-600 VAC, single or three-phase load, wye or delta.
Diagnostic LEDs
Confirms correct status of voltage and CT connections for reliable power and energy measurements.
Applications
- Energy - Energy storage for grid services
- Industry - Power quality and power monitoring
- Building - Metering and sub-billing
