Certificates and Declaration
| Proposition 65 California | WARNING This product can expose you to chemicals including Styrene, which is known to the State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov |
|---|
Technical Characteristics
| Fuse size | Size 3 |
|---|---|
| Number of poles | 4 (2//) |
| Rated current [A] | 1700 A |
| Type | KN/110 or DIN 43620 |
| Frame size | 2x2F4 |
Technical Characteristics - Electrical
| Rated voltage Ue [V] | 1035 |
|---|---|
| Rated insulation voltage Ui [V] | 1250 |
| Rated impulse withstand voltage Uimp [kV] | 12 |
| Load duty category | DC-20B |
Technical Characteristics - Mechanical
| Endurance (number of operating cycles) | 1500 |
|---|---|
| Operating torque [lbs.in/Nm] | 60 |
| Maximum connexion capacity per pole | 4x185mm² |
| Minimum connexion capacity per pole | 2x95mm² |
Technical Characteristics - Short-circuit capacity
| Short-circuit capacity at 1000 & 1500 VDC / Prospective short-circuit current [kA rms] | 35 |
|---|
ETIM - Electrical characteristics
| Max. rated operation voltage Ue AC [V] | 1035 |
|---|---|
| Number of poles | 4 |
Logistics
| GTIN/EAN | 3596031770878 |
|---|---|
| Customs number | 8535301090 |
| Price unit | PC |
| Weight of the packing unit [kg] | 32,5 |
| Length of the packing unit [m] | 0,52 |
| Width of the packing unit [m] | 0,8 |
| Depth of the packing unit [m] | 0,6 |
Product Details
| Effective date | 2004-11-04 |
|---|---|
| Offer Life Cycle Code | 40 |
| Country of origin | FR |
Classification
| UNSPSC | 39122233 |
|---|---|
| ETIM Class | EC001040 |
| IGCC | 5291 |
