RnVuY3Rpb24=

U29saWQgY29wcGVyIGJhcnMgZm9yIHByaW1hcnkgb3Igc2Vjb25kYXJ5IGRpc3RyaWJ1dGlvbiBidXNiYXJzLg==

Standards

Conformity to standards IEC

Technical Characteristics

Height [mm] 990
Width [mm] 32
Depth [mm] 5
Weight [kg] 1.36
Length 990
Model Prepunched and Threaded Bar
Thickness 5

ETIM - Electrical characteristics

Rated current In [A] 369

ETIM - Mechanical characteristics

Length [mm] 990
Width [mm] 32
Height [mm] 5
Surface protection Untreated

ETIM - Technical features

Model Other
Flexible No

Logistics

GTIN/EAN 3596031223817
Customs number 7407100000
Price unit PC
Weight of the packing unit [kg] 1.36
Length of the packing unit [m] 0.003
Width of the packing unit [m] 0.032
Depth of the packing unit [m] 0.991

Product Details

Effective date 1996-10-18
Offer Life Cycle Code 40
Country of origin FR

Classification

UNSPSC 26121634
ETIM Class EC001522
IGCC 1786

Documentation

Visit resource center
  • PDF
    Catalog pages EN-US
    646.78 KB
    Rigid copper bars - Busbar
    Download
    Select

References

Threaded copper bars is also available in 2 versions

Item Model Thickness Length Select
45121505 Prepunched and Threaded Bar 5 990
45122005 Prepunched and Threaded Bar 5 990
