Function

SOCOMEC insulated flat copper braids are mainly utilized for providing the power connections between series of distribution busbars and the upstream devices within
an electrical panel.
Their flexibility is especially adapted to achieve complex and customized connections in cases where minimum spaceis available.

=-=-=-=-=-=- System =-=-=-=-=-=-
Fill rate E-Order Common 100
Fill rate E-Order Selection 100
Standards
Conformity to standards
  • IEC
  • UL
Technical Characteristics
Height 32
Length 524
Model Insulated Copper Braid
Thickness 10
ETIM - Electrical characteristics
Rated current In [A] 630
ETIM - Mechanical characteristics
Length [mm] 524
Width [mm] 32
Height [mm] 10
Surface protection Other
ETIM - Technical features
Model Other
Flexible Yes
Logistics
GTIN/EAN 3596032741990
Customs number 8544499590
Price unit PC
Weight of the packing unit 1.24
Length of the packing unit 0.525
Width of the packing unit 0.04
Depth of the packing unit 0.005
Product Details
Effective date 2013-03-27
Country of origin FR
Discount Policy 1CK10
Discount Policy Label COPPER BAR
Length of the product unit 0.012
Width of the product unit 0.032
Depth of the product unit 0.524
Weight 1.24
Classification
UNSPSC 26121634
ETIM Class EC001522
IGCC 1786
