The DIRIS Digiware C-32 module is a bus repeater with a 24 VDC input that is used whenever the total power consumption exceeds the maximum consumption of the 24 VDC auxiliary power supply used. The C-32 repeater provides an additional 20 W and 100 meters to the Digiware bus.
A maximum of 2 repeaters can be used in the same system, allowing the Digiware bus to reach up to 300 meters.

=-=-=-=-=-=- System =-=-=-=-=-=-
Fill rate E-Order Common 25
Fill rate E-Order Selection 50
Certificates and Declaration
Conformity to standard #1 UL 61010-1 Guide PICQ File E257746
Conformity to standard #2 CSA-C22.2 No. 61010-1
Conformity to standard #3 IEC 61557-12
Conformity to standard #4 ISO 14025
Proposition 65 California WARNING This product can expose you to chemicals including bisphenol A (BPA), which is known to the State of California to cause birth defects or reproductive harm. For more information go to :
Conformity to standards
  • IEC
  • UL
Certificates and Declaration - Safety
Safety standards IEC/EN 61010-1 UL 61010-1 CAN/CSA C22.2 No. 61010-1
UL file number E257746
General Product Characteristics
Device type Repeater
Technical Characteristics
Model C-32
Size 1 Module
Type DIRIS Digiware Repeater
Technical Characteristics - Environmental
Maximum operating altitude 6560 feet / 2000 m
Operating temperature +14 to +158 °F / -10 to +70 °C
Relative humidity 131 °F / 55 °C / 97% HR
Storage temperature -13 to +158 °F / -25 to +70 °C
Technical Characteristics - Measurement
Degree of Pollution 2
ETIM - Technical features
Type of accessory/spare part Other
GTIN/EAN 3596032783822
Customs number 8543709099
Price unit PC
Weight of the packing unit 0.09
Length of the packing unit 0.03
Width of the packing unit 0.08
Depth of the packing unit 0.117
Product Details
Effective date 2014-01-22
Country of origin FR
Discount Policy 1EN60
UNSPSC 83101808
ETIM Class EC002295
IGCC 6042
