Certificates and Declaration
| Conformity to standard #1 | UL 61010-1 Guide PICQ File E257746 |
|---|---|
| Conformity to standard #2 | CSA-C22.2 No. 61010-1 |
| Conformity to standard #3 | IEC 61557-12 |
| Conformity to standard #4 | E257746 |
| Proposition 65 California | WARNING This product can expose you to chemicals including bisphenol A (BPA), which is known to the State of California to cause birth defects or reproductive harm. For more information go to : www.P65Warnings.ca.gov |
Standards
| Conformity to standards |
|
|---|
Certificates and Declaration - Safety
| Safety standards |
IEC/EN 61010-1 UL 61010-1 CAN/CSA C22.2 No. 61010-1 |
|---|---|
| UL file number | E257746 |
General Product Characteristics
| Device type | Step-down DC voltage adaptor for DIRIS Digiware DC |
|---|
Technical Characteristics
| Model | U1500DC |
|---|---|
| Type | DC voltage adapter U1500dc 1200-1650 VDC |
Technical Characteristics - Environmental
| Maximum operating altitude | 6560 feet / 2000 m |
|---|---|
| Operating temperature | 14 ... 131 °F / -10 … +55°C |
| PEP ecopassport - ISO 14025 | SOCO-00008-V01.01-EN |
| Relative humidity | 131 °F / 55 °C / 97% relative humidity |
| Storage temperature | -13 ... 158 °F / -25 … +70°C |
Technical Characteristics - Measurement
| Voltage measurement type | DC |
|---|
ETIM - Technical features
| Type of accessory/spare part | Other |
|---|
Logistics
| GTIN/EAN | 3596033002878 |
|---|---|
| Customs number | 8504409590 |
| Price unit | PC |
| Weight of the packing unit [kg] | 0.12 |
| Length of the packing unit [m] | 0.06 |
| Width of the packing unit [m] | 0.08 |
| Depth of the packing unit [m] | 0.13 |
Product Details
| Effective date | 2018-02-01 |
|---|---|
| Offer Life Cycle Code | 40 |
| Country of origin | FR |
Classification
| UNSPSC | 83101808 |
|---|---|
| ETIM Class | EC002295 |
| IGCC | 6042 |
Documentation
References
DIRIS Digiware Udc Adaptor is also available in 2 versions
| Item | Type | Model | Select |
|---|---|---|---|
| 48290154 | DC voltage adapter U1000dc 400-1200 VDC | U1000DC | |
| 48290153 | DC voltage adapter U500dc 200-600 VDC | U500DC |
