Standards
| Conformity to standards |
|
|---|
Technical Characteristics
| Height [mm] | 1000 |
|---|---|
| Color | Red, Black, Yellow, Blue |
| Connector | RJ12 |
| Length | 1 m |
| Type | Connection cable for TE, TR/iTR, TF current sensors |
ETIM - Mechanical characteristics
| Length [m] | 1 |
|---|---|
| Colour outer sheath | Grey |
| Anti-kink sleeve | None |
| Cable construction | Other |
| AWG-size | 26 |
| Cable type | U/UTP |
ETIM - Technical features
| Category | 5 |
|---|---|
| Type of connector connection 1 | RJ12 6(6) |
| Type of connector connection 2 | RJ12 6(6) |
| Locking lever | No |
| Fire retardant version | No |
| Oil resistant according to EN IEC 60811-404 | Yes |
| Pin assignment | 1:1 |
| NVP value [%] | 70 |
Logistics
| GTIN/EAN | 3596032776640 |
|---|---|
| Customs number | 8544429090 |
| Price unit | PC |
| Weight of the packing unit [kg] | 0.12 |
| Length of the packing unit [m] | 0.1 |
| Width of the packing unit [m] | 0.135 |
| Depth of the packing unit [m] | 0.03 |
Product Details
| Effective date | 2013-11-22 |
|---|---|
| Offer Life Cycle Code | 40 |
| Country of origin | TH |
Classification
| UNSPSC | 83101808 |
|---|---|
| ETIM Class | EC001262 |
| IGCC | 6042 |
