U3Ryb25nIFBvaW50cw==

  • SW5zdWxhdGluZyBtYXRlcmlhbHM=

  • RHVyYWJpbGl0eQ==

  • QWRhcHRhYmlsaXR5

RnVuY3Rpb24=

SW5zdWxhdGluZyBidXNiYXIgc3VwcG9ydHMgdG8gbW91bnQgY29wcGVyIG9yIGFsdW1pbml1bSBidXNiYXJzLCB0ZXN0ZWQgdG8gaG9sZCB0aGVtIHNlY3VyZWx5IGR1cmluZyBhIHNob3J0IGNpcmN1aXQu

Standards

Conformity to standards IEC

Technical Characteristics

Busbar distance 500..1000
Number of poles 1
Rated voltage 690 VAC
Section 32..63x5

ETIM - Electrical characteristics

Number of poles 1
Max. rated current [A] 1000

Logistics

GTIN/EAN 3596031235278
Customs number 8546901000
Price unit PC
Weight of the packing unit [kg] 0.16
Length of the packing unit [m] 0.135
Width of the packing unit [m] 0.1
Depth of the packing unit [m] 0.03

Product Details

Effective date 1988-04-15
Offer Life Cycle Code 40
Country of origin FR

Classification

UNSPSC 39121321
ETIM Class EC001166
IGCC 4462

Documentation

Visit resource center
  • PDF
    Catalog pages EN-US
    3.53 MB
    BUSBAR SUPPORTS
    Download
    Select

References

SB 3 busbar support is also available in 1 version

Item Section Number of poles Rated voltage Busbar distance Select
50230111 32..63x5 1 690 VAC
