Strong Points
Function
The 24 VDC Power supplies are used for DIRIS Digiware Digiware system.
The power supplies are connected to system interfaces (D-xx display, M-xx gateway or C-31 interface) which in turn power the entire system thanks to the Digiware bus.
Conformity to standards
EN 60204-1 / Overvoltage category III
IEC 60950-1 (SELV) and EN 60204-1 (PELV)
UL/C-UL listed UL 508
UL/C-UL Recognized UL 60950
NEC Class 2 as per UL 1310
References
24 VDC power supply is available in 2 versions
| Item | Model | Input voltage | Output voltage | Output power | Select |
|---|---|---|---|---|---|
| 48290120 | P15 | 100-240 Vac | 24 Vdc | 15 W | |
| 47290603 | P30 | 100-240 Vac | 24 Vdc | 30 W |
Advantages
Easy mounting
Easy assembly on a DIN rail or back plate
Reliable
Quick startup with LED function monitoring
Redundancy
Parallel connection possible for increased performance and redundancy
