U3Ryb25nIFBvaW50cw==
-
UmVsaWFiaWxpdHkgYW5kIHBlcmZvcm1hbmNl
-
U2FmZXR5IG9mIHByb3BlcnR5IGFuZCBwZXJzb25uZWw=
-
U2ltcGxpY2l0eQ==
-
RWFzeSB0byBpbnN0YWxs
RnVuY3Rpb24=
Technical Characteristics
| Number of poles | 3 |
|---|---|
| Rated voltage | 800 VAC |
| Rated current [A] | 1000 |
| Type | Front operation |
| Frame size | B7 |
ETIM - Electrical characteristics
| Max. rated operation voltage Ue AC [V] | 800 |
|---|---|
| Rated operating voltage [V] | 400..800 |
| Rated permanent current Iu [A] | 1000 |
ETIM - Mechanical characteristics
| Suitable for floor mounting | No |
|---|---|
| Suitable for front mounting 4-hole | Yes |
| Suitable for front mounting centre | No |
| Suitable for distribution board installation | Yes |
| Suitable for intermediate mounting | Yes |
| Colour control element | White |
ETIM - Technical features
| Version as main switch | Yes |
|---|---|
| Version as maintenance-/service switch | Yes |
| Version as safety switch | Yes |
| Version as emergency stop installation | Yes |
| Version as reversing switch | No |
| Number of switches | 1 |
| Motor drive optional | No |
| Motor drive integrated | No |
| Voltage release optional | No |
| Device construction | Built-in device fixed built-in technique |
| Type of control element | Long turning handle |
| Interlockable | Yes |
| Type of electrical connection of main circuit | Bolt connection |
| With pre-assembled cabling | No |
Logistics
| GTIN/EAN | 3596033289446 |
|---|---|
| Customs number | 8536508000 |
| Price unit | PC |
Classification
| UNSPSC | 39122233 |
|---|---|
| ETIM Class | EC000216 |
Certificates and Declaration
| Conformity to standard #1 | UL98C |
|---|---|
| Proposition 65 California | WARNING This product can expose you to chemicals including Styrene, which is known to the State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov |
Standards
| Conformity to standards | UL |
|---|
Product Details
| Effective date | 2023-10-31 |
|---|---|
| Offer Life Cycle Code | 40 |
| Country of origin | FR |
