U3Ryb25nIFBvaW50cw==
-
SGlnaCBicmVha2luZyBjYXBhY2l0eQ==
-
Um9idXN0IGFuZCBlcmdvbm9taWMgaGFuZGxl
RnVuY3Rpb24=
Certificates and Declaration
| Proposition 65 California | WARNING This product can expose you to chemicals including Styrene, which is known to the State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov |
|---|
Standards
| Conformity to standards | UL |
|---|
Technical Characteristics
| Height [mm] | 1219 |
|---|---|
| Width [mm] | 914 |
| Depth [mm] | 305 |
| Number of poles | 3 |
| Rated current [A] | 600 |
ETIM - Electrical characteristics
| Max. rated operation voltage Ue AC [V] | 600 |
|---|---|
| Rated permanent current Iu [A] | 600 |
| Rated short-time withstand current lcw [kA] | 600 |
| Number of poles | 3 |
ETIM - Mechanical characteristics
| Cable entry | Top/bottom |
|---|---|
| Equipped with connectors | No |
| Suitable for floor mounting | No |
| Suitable for front mounting | No |
| Suitable for busbar mounting | No |
ETIM - Technical features
| Version as main switch | No |
|---|---|
| Version as safety switch | Yes |
| With error protection | No |
| Type of electrical connection of main circuit | Screw connection |
| Type of control element | Door coupling rotary drive |
| Position control element | Front side |
| Motor drive optional | No |
| Motor drive integrated | No |
| Version as emergency stop installation | Yes |
Logistics
| GTIN/EAN | 3596033022876 |
|---|---|
| Customs number | 8537109899 |
| Price unit | PC |
| Weight of the packing unit [kg] | 85 |
Product Details
| Effective date | 2019-01-01 |
|---|---|
| Offer Life Cycle Code | 40 |
| Country of origin | MX |
Classification
| UNSPSC | 39122205 |
|---|---|
| ETIM Class | EC001040 |
| IGCC | 5168 |
