U3Ryb25nIFBvaW50cw==

  • RWFzeSBpbnRlZ3JhdGlvbg==

  • VW5wYXJhbGxlbGVkIHNlcnZpY2VhYmlsaXR5

  • QmVzdCByZXNpbGllbmN5

  • Um9idXN0IGRlc2lnbg==

RnVuY3Rpb24=

U1RBVFlTIEludGVncmFibGUgaXMgYSBmdWxseSBpbnRlZ3JhdGVkIHN0YXRpYyB0cmFuc2ZlciBwb3dlciB1bml0IGZvciBpbnRlZ3JhdGlvbiBpbnRvIGEgY2FiaW5ldCBvciBhIHBvd2VyIGRpc3RyaWJ1dGlvbiB1bml0IChQRFUpLjxiciAvPg0KU3VwcGxpZWQgYnkgdHdvIGluZGVwZW5kZW50IHNvdXJjZXMsIFNUQVRZUyBJbnRlZ3JhYmxlIGluY3JlYXNlcyB0aGUgb3ZlcmFsbCBlbGVjdHJpY2FswqBpbmZyYXN0cnVjdHVyZSBhdmFpbGFiaWxpdHkgZHVyaW5nIGFibm9ybWFsIGV2ZW50cyBhbmQgcHJvZ3JhbW1lZCBtYWludGVuYW5jZS4=

Environmental Sustainability

Climate change - Total - Cradle to Grave [kg CO₂ eq.] 52404
Climate change - Total - Cradle to Gate [kg CO₂ eq.] 1981
SVHC > 0.1 mass percentage? No
RoHS applicable? Yes

Technical Characteristics

Height [mm] 995
Width [mm] 848
Depth [mm] 650
Weight [kg] 295
In/out 3/3
Length 650
Number of poles 3
Output voltage 480
Rated frequency 60/60
Rated current [A] 200
Input voltage 480
Rate (min) 200
Rate (max) 200
LTM Protection NoFuse
Switching Poles 3P

ETIM - Mechanical characteristics

Width [mm] 848
Height [mm] 995
Depth [mm] 650

Logistics

GTIN/EAN 3596033174780
Customs number 8536500500
Price unit PC

Product Details

Effective date 2021-01-10
Offer Life Cycle Code 40
Country of origin FR

Classification

ETIM Class EC002850

Documentation

Visit resource center
  • PDF
    Catalog pages EN-US
    1.02 MB
    STATYS Integrable Redundant design for power availability and site maintainability
