U3Ryb25nIFBvaW50cw==
-
RWFzeSBpbnRlZ3JhdGlvbg==
-
VW5wYXJhbGxlbGVkIHNlcnZpY2VhYmlsaXR5
-
QmVzdCByZXNpbGllbmN5
-
Um9idXN0IGRlc2lnbg==
RnVuY3Rpb24=
Environmental impact
| Carbon footprint - Lifecycle total [kg CO₂ eq.] | 52404 |
|---|---|
| Carbon footprint - Manufacturing [A1-A3] [kg CO₂ eq.] | 1981 |
| PEP Filename | SOCO-00086-V01.01-EN.pdf |
Materials and substances
| EU REACH | Does not contain SVHC |
|---|---|
| EU RoHS | Compliant |
Technical Characteristics
| Height [mm] | 995 |
|---|---|
| Width [mm] | 848 |
| Depth [mm] | 650 |
| Weight [kg] | 295 |
| In/out | 3/3 |
| Length | 650 |
| Number of poles | 4 |
| Output voltage | 400 |
| Rated frequency | 60/60 |
| Rated current [A] | 200 |
| Input voltage | 400 |
| Rate (min) | 200 |
| Rate (max) | 200 |
| LTM Protection | NoFuse |
| Switching Poles | 4P |
ETIM - Mechanical characteristics
| Width [mm] | 848 |
|---|---|
| Height [mm] | 995 |
| Depth [mm] | 650 |
ETIM - Technical features
| Type of accessory/spare part | Switch unit |
|---|---|
| Accessory | Yes |
| Spare part | No |
Logistics
| GTIN/EAN | 3596033174810 |
|---|---|
| Customs number | 8536500500 |
| Price unit | PC |
Product Details
| Effective date | 2021-01-10 |
|---|---|
| Offer Life Cycle Code | 40 |
| Country of origin | FR |
Classification
| UNSPSC | 39122200 |
|---|---|
| ETIM Class | EC002850 |
