RnVuY3Rpb24=

U29saWQgY29wcGVyIGJhcnMgZm9yIHByaW1hcnkgb3Igc2Vjb25kYXJ5IGRpc3RyaWJ1dGlvbiBidXNiYXJzLg==

Standards

Conformity to standards IEC

Technical Characteristics

Height [mm] 1750
Width [mm] 63
Depth [mm] 5
Weight [kg] 4.35
Length 1750
Model Prepunched Bar
Thickness 5

ETIM - Electrical characteristics

Rated current In [A] 630

ETIM - Mechanical characteristics

Length [mm] 1750
Width [mm] 63
Height [mm] 5
Surface protection Untreated

ETIM - Technical features

Model Other
Flexible No

Logistics

GTIN/EAN 3596031223756
Customs number 7407100000
Price unit PC
Weight of the packing unit [kg] 4.35
Length of the packing unit [m] 0.005
Width of the packing unit [m] 0.063
Depth of the packing unit [m] 1.75

Product Details

Effective date 1996-08-08
Offer Life Cycle Code 40
Country of origin FR

Classification

UNSPSC 26121634
ETIM Class EC001522
IGCC 1786

Documentation

Visit resource center
  • PDF
    Catalog pages EN-US
    646.78 KB
    Rigid copper bars - Busbar
    Download
    Select

References

Prepunched copper bars is also available in 10 versions

Item Model Thickness Length Select
45119010 Prepunched Bar 10 1750
45119005 Prepunched Bar 5 1750
45119210 Prepunched Bar 10 1750
45119205 Prepunched Bar 5 1750
45112505 Prepunched Bar 5 1750
45115010 Prepunched Bar 10 1750
45115005 Prepunched Bar 5 1750
45116010 Prepunched Bar 10 1750
45118010 Prepunched Bar 10 1750
45118005 Prepunched Bar 5 1750
