Strong Points

  • View more Created with sketchtool.

    Easy setup

  • View more Created with sketchtool.

    Increased safety without crimped connections

  • View more Created with sketchtool.



SOCOMEC insulated flexible copper bars are mainly utilized for providing the power connections between series of distribution busbars and the upstream devices within an electrical panel.
The insulated layered copper allows the flexible copper bar to be easily formed to provide a customized solution.

Certificates and Declaration
Conformity to standard #1 UL 67 and UL891 Guide QUEY File E495516
Conformity to standard #2 CSA-22.2 No. 29 and 244
Proposition 65 California WARNING This product can expose you to chemicals including Styrene, Formaldehyde which is known to the State of California to cause cancer. For more information go to:
Conformity to standards IEC
Certificates and Declaration - Safety
UL file number E495516
Technical Characteristics
Height 13
Length 2000
Model Insulated Flexible Copper Bar
Thickness 0.5
Number of layers 4
Technical Characteristics - Environmental
Operating temperature -4 ... +122°F / -20 ... +50°C
Storage temperature -40 ... +158°F / -40 ... +70°C
Technical Characteristics - Short-circuit capacity
UL General use rating 165
ETIM - Electrical characteristics
Rated current In [A] 165
ETIM - Mechanical characteristics
Length [mm] 2000
Width [mm] 13
Height [mm] 0.5
Surface protection Other
ETIM - Technical features
Model Other
Flexible Yes
GTIN/EAN 3596031224555
Customs number 7409190090
Price unit PC
Weight of the packing unit 0.66
Length of the packing unit 0.03
Width of the packing unit 0.04
Depth of the packing unit 2
Product Details
Effective date 2000-08-01
Country of origin DE
Discount Policy 1CK10
Discount Policy Label COPPER BAR
Length of the product unit 0.0005
Width of the product unit 0.013
Depth of the product unit 2
Weight 0.66
UNSPSC 26121634
ETIM Class EC001522
IGCC 1786
