Certificates and Declaration
| Conformity to standard #1 | UL 67 and UL891 Guide QUEY File E495516 |
|---|---|
| Conformity to standard #2 | CSA-22.2 No. 29 and 244 |
| Proposition 65 California | WARNING This product can expose you to chemicals including Styrene, Formaldehyde which is known to the State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov |
Standards
| Conformity to standards | IEC |
|---|
Certificates and Declaration - Safety
| UL file number | E495516 |
|---|
Technical Characteristics
| Height | 20 |
|---|---|
| Length | 2000 |
| Model | Insulated Flexible Copper Bar |
| Thickness | 1 |
| Number of layers | 5 |
Technical Characteristics - Environmental
| Operating temperature | -4 ... +122°F / -20 ... +50°C |
|---|---|
| Storage temperature | -40 ... +158°F / -40 ... +70°C |
Technical Characteristics - Short-circuit capacity
| UL General use rating [A] | 374 |
|---|
ETIM - Electrical characteristics
| Rated current In [A] | 374 |
|---|
ETIM - Mechanical characteristics
| Length [mm] | 2000 |
|---|---|
| Width [mm] | 20 |
| Height [mm] | 1 |
| Surface protection | Other |
ETIM - Technical features
| Model | Other |
|---|---|
| Flexible | Yes |
Logistics
| GTIN/EAN | 3596031224678 |
|---|---|
| Customs number | 7409190000 |
| Price unit | PC |
| Weight of the packing unit [kg] | 2.33 |
| Length of the packing unit [mm] | 0.005 |
| Width of the packing unit [mm] | 0.02 |
| Depth of the packing unit [mm] | 2 |
Product Details
| Effective date | 2000-08-01 |
|---|---|
| Country of origin | DE |
| Length of the product unit [mm] | 0.001 |
| Width of the product unit [mm] | 0.02 |
| Depth of the product unit [mm] | 2 |
| Weight [kg] | 2.33 |
Classification
| UNSPSC | 26121634 |
|---|---|
| ETIM Class | EC001522 |
| IGCC | 1786 |
