U3Ryb25nIFBvaW50cw==

  • UGx1ZyAmIFBsYXk=

  • QWR2YW5jZWQgY29ubmVjdGl2aXR5

  • RW1iZWRkZWQgd2ViIHNlcnZlcg==

  • Q3liZXIgc2VjdXJpdHk=

  • RW1haWwgbm90aWZpY2F0aW9ucw==

RnVuY3Rpb24=

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

=-=-=-=-=-=- System =-=-=-=-=-=-
Fill rate E-Order Common 29
Fill rate E-Order Selection 60
Certificates and Declaration
Conformity to standard #1 UL 61010-1 Guide PICQ File E257746
Conformity to standard #2 CSA-C22.2 No. 61010-1
Conformity to standard #3 IEC 62974-1
Conformity to standard #4 E257746
Proposition 65 California WARNING This product can expose you to chemicals including bisphenol A (BPA), which is known to the State of California to cause birth defects or reproductive harm. For more information go to : www.P65Warnings.ca.gov
Standards
Conformity to standards
  • IEC
  • UL
Certificates and Declaration - Safety
UL file number E257746
General Product Characteristics
Device type Communication gateway with embedded webserver
Technical Characteristics
Communication ports RS485 - Ethernet - Digiware - USB
Communication protocols Modbus RTU - Modbus TCP - SNMP v1, v2, v3 & Traps - BACnet IP - HTTP(S) - FTP(S) - SMTP(S) - Bluetooth Low Energy
Model M-50
Type Communication gateway interface for DIRIS Digiware system
Technical Characteristics - Environmental
Maximum operating altitude 6560 feet / 2000 m
Operating temperature 14 ... 131 °F / -10 … +55°C
Relative humidity 95% at 104 °F / 40 °C
Storage temperature -13 ... 158 °F / -25 … +70°C
ETIM - Electrical characteristics
Bus system KNX No
Bus system KNX-RF (Radio Frequent) No
Bus system radio frequent No
Bus system LON No
Bus system Powernet No
Radio frequent bidirectional No
Operating voltage [V] 0..24
Voltage type DC
Power consumption [W] 2.5
ETIM - Mechanical characteristics
Width in number of modular spacings 5
Degree of protection (IP) IP20
ETIM - Technical features
Model Ethernet interface
Number of channels 1
Max. number of devices per channel 32
Demounting protection No
With LED indication Yes
Updateable Yes
Protocol TCP/IP
Provider dependent No
Visualization No
Web-Server Yes
Radio interface No
IR interface No
Logistics
GTIN/EAN 3596033071133
Customs number 8517620000
Price unit PC
Weight of the packing unit 0.256
Length of the packing unit 0.09
Width of the packing unit 0.132
Depth of the packing unit 0.105
Product Details
Effective date 2019-11-15
Country of origin FR
Discount Policy 1EN40
Discount Policy Label GATEWAYS & CONCENTRATORS
Classification
UNSPSC 83101808
ETIM Class EC001099
IGCC 6042
