Certificates and Declaration
| Conformity to standard #1 | UL 61010-1 Guide PICQ File E257746 |
|---|---|
| Conformity to standard #2 | CSA-C22.2 No. 61010-1 |
| Conformity to standard #3 | IEC 62443 |
| Conformity to standard #4 | E257746 |
| Proposition 65 California | WARNING This product can expose you to chemicals including bisphenol A (BPA), which is known to the State of California to cause birth defects or reproductive harm. For more information go to : www.P65Warnings.ca.gov |
Environmental impact
| Carbon footprint - Lifecycle total [kg CO₂ eq.] | 128 |
|---|---|
| Carbon footprint - Manufacturing [A1-A3] [kg CO₂ eq.] | 21 |
| PEP Filename | SOCO-00044-V01.02-EN.pdf |
Materials and substances
| EU REACH | Does not contain SVHC |
|---|---|
| EU RoHS | Compliant |
Standards
| Conformity to standards |
|
|---|
Certificates and Declaration - Safety
| UL file number | E257746 |
|---|
General Product Characteristics
| Device type | Communication gateway with embedded webserver |
|---|
Technical Characteristics
| Height [mm] | 114 |
|---|---|
| Width [mm] | 89 |
| Depth [mm] | 65 |
| Communication ports | RS485 - Ethernet - Digiware - USB |
| Communication protocols | Modbus RTU - Modbus TCP - SNMP v1, v2, v3 & Traps - BACnet IP - HTTP(S) - FTP(S) - SMTP(S) - Bluetooth Low Energy |
| Model | M-70 |
| Type | Communication gateway interface for DIRIS Digiware system |
Technical Characteristics - Environmental
| Maximum operating altitude | 6560 feet / 2000 m |
|---|---|
| Operating temperature | 14 ... 131 °F / -10 … +55°C |
| Relative humidity | 95% at 104 °F / 40 °C |
| Storage temperature | -13 ... 158 °F / -25 … +70°C |
ETIM - Electrical characteristics
| Bus system KNX | No |
|---|---|
| Bus system KNX-RF (Radio Frequent) | No |
| Bus system radio frequent | No |
| Bus system LON | No |
| Bus system Powernet | No |
| Radio frequent bidirectional | No |
| Operating voltage [V] | 0..24 |
| Voltage type | DC |
| Power consumption [W] | 2.5 |
ETIM - Mechanical characteristics
| Width in number of modular spacings | 5 |
|---|---|
| Degree of protection (IP) | IP20 |
ETIM - Technical features
| Number of channels | 1 |
|---|---|
| Max. number of devices per channel | 32 |
| Model | Ethernet interface |
| Demounting protection | No |
| With LED indication | Yes |
| Updateable | Yes |
| Provider dependent | No |
| Visualization | Yes |
| Web-Server | Yes |
| Protocol | TCP/IP |
| Radio interface | No |
| IR interface | No |
Logistics
| GTIN/EAN | 3596033071140 |
|---|---|
| Customs number | 8517620000 |
| Price unit | PC |
| Weight of the packing unit [kg] | 0.3 |
| Length of the packing unit [m] | 0.09 |
| Width of the packing unit [m] | 0.135 |
| Depth of the packing unit [m] | 0.105 |
Product Details
| Effective date | 2019-11-15 |
|---|---|
| Offer Life Cycle Code | 40 |
| Country of origin | FR |
Classification
| UNSPSC | 83101808 |
|---|---|
| ETIM Class | EC001099 |
| IGCC | 6042 |
