U3Ryb25nIFBvaW50cw==

  • SW5zdWxhdGluZyBtYXRlcmlhbHM=

  • RHVyYWJpbGl0eQ==

  • QWRhcHRhYmlsaXR5

RnVuY3Rpb24=

SW5zdWxhdGluZyBidXNiYXIgc3VwcG9ydHMgdG8gbW91bnQgY29wcGVyIG9yIGFsdW1pbml1bSBidXNiYXJzLCB0ZXN0ZWQgdG8gaG9sZCB0aGVtIHNlY3VyZWx5IGR1cmluZyBhIHNob3J0IGNpcmN1aXQu

Standards

Conformity to standards IEC

Technical Characteristics

Height [mm] 80
Width [mm] 46
Depth [mm] 46
Weight [kg] 0.16
Diameter M10
Rated voltage 2000 VAC/DC
Type Male-female

ETIM - Electrical characteristics

Number of poles 1

Logistics

GTIN/EAN 3596031995905
Customs number 8546901000
Price unit PC
Weight of the packing unit [kg] 0.16
Length of the packing unit [m] 0.075
Width of the packing unit [m] 0.05
Depth of the packing unit [m] 0.05

Product Details

Effective date 2010-02-25
Offer Life Cycle Code 40
Country of origin IN

Classification

UNSPSC 39121321
ETIM Class EC001166
IGCC 4462

Documentation

Visit resource center
  • PDF
    Catalog pages EN-US
    3.53 MB
    BUSBAR SUPPORTS
    Download
    Select

References

Male to female hexagonal insulator is also available in 8 versions

Item Rated voltage Select
50383510 1400 VAC/DC
50383508 1400 VAC/DC
50385008 2000 VAC/DC
50386010 2400 VAC/VDC
50381604 500 VAC/DC
50381605 500 VAC/DC
50382505 500 VAC/DC
50382506 500 VAC/DC
