U3Ryb25nIFBvaW50cw==

  • RXh0ZW5zaXZlIHJhbmdl

  • SUVDIGFuZCBVTCByYW5nZQ==

  • RWFzeSBpbnRlZ3JhdGlvbg==

RnVuY3Rpb24=

RGlzdHJpYnV0b3JzIHByb3ZpZGUgYW4gZWFzeSBjb25uZWN0aW9uIHRvIGNvbmR1Y3RvcnMuIFRoZXkgYXJlIG1vdW50ZWQgZG93bnN0cmVhbSBvZiBhIGxvYWQgYnJlYWsgc3dpdGNoLCBjaGFuZ2VvdmVyIHN3aXRjaCwgYSBmdXNlIHN3aXRjaCBvciBhbnkgcHJvdGVjdGlvbiBkZXZpY2Ugb24gdGhlIG1hcmtldC4=

=-=-=-=-=-=- System =-=-=-=-=-=-
Fill rate E-Order Common 86
Fill rate E-Order Selection 100
Certificates and Declaration
Conformity to standard #1 UL 1059 Guide XCFR, File E500524
Conformity to standard #2 CSA-C22.2 N0. 128
Conformity to standard #3 IEC 60947-7-1
Proposition 65 California WARNING This product can expose you to chemicals including Styrene, Formaldehyde which is known to the State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov
Standards
Conformity to standards
  • IEC
  • UL
Certificates and Declaration - Safety
UL file number E500524
Technical Characteristics
Number of conductors 7
Number of poles 3
Rated current [A] 175
Technical Characteristics - Connection terminals
Max. connection section / AWG 2/0 (Line) , 6x 4AWG (Load)
Min. connection section / AWG 8 AWG (Line), 6x 14AWG (Load)
Technical Characteristics - Environmental
Operating temperature -4 ... +122°F / -20 ... +50°C
Storage temperature -40 ... +158°F / -40 ... +70°C
Technical Characteristics - Short-circuit capacity
UL General use rating 175 (Cu) / 135 (Al)
ETIM - Mechanical characteristics
Number of poles 3
With seal head No
Logistics
GTIN/EAN 3596033047626
Customs number 8536901000
Price unit PC
Weight of the packing unit 0.208
Length of the packing unit 0.05
Width of the packing unit 0.1
Depth of the packing unit 0.1
Product Details
Effective date 2018-03-06
Country of origin FR
Discount Policy 1CK30
Discount Policy Label CONNECTION DEVICE
Length of the product unit 0.08
Width of the product unit 0.071
Depth of the product unit 0.049
Weight 0.21
Classification
UNSPSC 39121421
ETIM Class EC000276
IGCC 4586
