U3Ryb25nIFBvaW50cw==

  • RXh0ZW5zaXZlIHJhbmdl

  • SUVDIGFuZCBVTCByYW5nZQ==

  • RWFzeSBpbnRlZ3JhdGlvbg==

RnVuY3Rpb24=

RGlzdHJpYnV0b3JzIHByb3ZpZGUgYW4gZWFzeSBjb25uZWN0aW9uIHRvIGNvbmR1Y3RvcnMuIFRoZXkgYXJlIG1vdW50ZWQgZG93bnN0cmVhbSBvZiBhIGxvYWQgYnJlYWsgc3dpdGNoLCBjaGFuZ2VvdmVyIHN3aXRjaCwgYSBmdXNlIHN3aXRjaCBvciBhbnkgcHJvdGVjdGlvbiBkZXZpY2Ugb24gdGhlIG1hcmtldC4=

Certificates and Declaration

Proposition 65 California WARNING This product can expose you to chemicals including Styrene, Formaldehyde which is known to the State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov

Standards

Conformity to standards
  • IEC
  • UL

Technical Characteristics

Height [mm] 98
Width [mm] 74.5
Depth [mm] 49
Weight [kg] 0.365
Number of conductors 8
Number of poles 4
Rated current [A] 125

ETIM - Mechanical characteristics

Number of poles 4
With seal head No

Logistics

GTIN/EAN 3596033047633
Customs number 8536901000
Price unit PC
Weight of the packing unit [kg] 0.365
Length of the packing unit [m] 0.13
Width of the packing unit [m] 0.085
Depth of the packing unit [m] 0.05

Product Details

Effective date 2018-03-06
Offer Life Cycle Code 40
Country of origin FR

Classification

UNSPSC 39121421
ETIM Class EC000276
IGCC 4586

Documentation

Visit resource center
  • Mechanical view EN-US
    BLOCK 4P CD 125A CAD 54114112
    Ask

References

Power distribution blocks three-pole UR is also available in 1 version

Item Rated current [A] Number of poles Number of conductors Select
54113017 175 3 7
