Technical Characteristics
| Height [mm] | 211 |
|---|---|
| Width [mm] | 92 |
| Depth [mm] | 74.5 |
| Fuse size | 3 |
| Rated voltage | 1500 |
| Rated current [A] | 550 |
ETIM - Electrical characteristics
| Voltage type | DC |
|---|---|
| Rated current [A] | 550 |
| Rated voltage DC [V] | 1500 |
| Rated switching capacity DC [kA] | 250 |
| Utilization category | aR (accompanied semiconductor protection) |
| Power loss at rated current [W] | 211 |
Environmental impact
| Carbon footprint - Lifecycle total [kg CO₂ eq.] | 635 |
|---|---|
| Carbon footprint - Manufacturing [A1-A3] [kg CO₂ eq.] | 8 |
| PEP Filename | SOCO-00124-V01.01-EN.pdf |
Materials and substances
| EU REACH | Does not contain SVHC |
|---|---|
| EU RoHS | Compliant |
Logistics
| Customs number | 8535100090 |
|---|---|
| Price unit | PC |
Classification
| UNSPSC | 39121612 |
|---|---|
| ETIM Class | EC000055 |
Product Details
| Effective date | 2024-05-01 |
|---|---|
| Offer Life Cycle Code | 40 |
| Country of origin | CN |
