Environmental impact
| Carbon footprint - Lifecycle total [kg CO₂ eq.] | 885 |
|---|---|
| Carbon footprint - Manufacturing [A1-A3] [kg CO₂ eq.] | 10 |
| PEP Filename | SOCO-00125-V01.01-EN.pdf |
Materials and substances
| EU REACH | Does not contain SVHC |
|---|---|
| EU RoHS | Compliant |
Technical Characteristics
| Height [mm] | 152 |
|---|---|
| Width [mm] | 121 |
| Depth [mm] | 105 |
| Fuse size | 4 |
| Rated voltage | 1500 |
| Rated current [A] | 1600 |
ETIM - Electrical characteristics
| Voltage type | DC |
|---|---|
| Rated current [A] | 1600 |
| Rated voltage DC [V] | 1500 |
| Rated switching capacity DC [kA] | 250 |
| Utilization category | aR (accompanied semiconductor protection) |
| Power loss at rated current [W] | 294 |
Logistics
| GTIN/EAN | 3596033370434 |
|---|---|
| Customs number | 8535100090 |
| Price unit | PC |
Product Details
| Effective date | 2024-05-01 |
|---|---|
| Offer Life Cycle Code | 40 |
| Country of origin | CN |
Classification
| UNSPSC | 39121612 |
|---|---|
| ETIM Class | EC000055 |
