Function

INOSYS ESS LBS is a range of load break switches that can be controlled manually. These switches can be operated manually using the handle to disconnect all or part of an electrical installation. They ensure on-load opening and closing and safe disconnection of all direct current low voltage electrical circuits up to 1500 VDC. They can also be used for emergency disconnection applications. They have been designed specifically to withstand high short circuit conditions in DC and ESS applications.

=-=-=-=-=-=- System =-=-=-=-=-=-
Fill rate E-Order Common 33
Fill rate E-Order Selection 33
Certificates and Declaration
Conformity to standard #1 UL98B
Conformity to standard #2 IEC 60947-3
Proposition 65 California WARNING This product can expose you to chemicals including Styrene, which is known to the State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov
Certificates and Declaration - Safety
UL file number E346418
Technical Characteristics
Control operator Direct : E3 / External : S2L
Number of poles 2//2
Rated voltage 1500
Rated current [A] 800
Type Frontal operation
Frame size F3
Technical Characteristics - Connection terminals
Max. connection section / AWG 4x600MCM
Min. connection section / AWG 4x#2
Technical Characteristics - Environmental
Operating temperature -4 ... +122°F / -20 ... +50°C
Storage temperature -40 ... +158°F / -40 ... +70°C
Technical Characteristics - Mechanical
Endurance (number of operating cycles) 8000
Technical Characteristics - Short-circuit capacity
Operation voltage 2 P - 3/4 P 1500VDC
Short-circuit capacity at 1000 & 1500 VDC / Prospective short-circuit current 120
UL General use rating 800
Logistics
GTIN/EAN 3596031107964
Customs number 8535301090
Price unit PC
Weight of the packing unit 6.3
Product Details
Effective date 2022-11-01
Obsolescence date 2099-01-01
Production ban date 2099-01-01
Country of origin TN
Discount Policy 1CD40
Discount Policy Label INOSYS LBS PV MANUAL
Classification
UNSPSC 39122233
ETIM Class EC000216
IGCC 5290
