U3Ryb25nIFBvaW50cw==
-
SGlnaCBzaG9ydCBjaXJjdWl0IHdpdGhzdGFuZCBpbiBEQyBhbmQgRVNTIGFwcGxpY2F0aW9ucw==
-
SGlnaC1wZXJmb3JtYW5jZSBzd2l0Y2hpbmcgaW4gYSBzbWFsbCB2b2x1bWU=
-
U2FmZSBvcGVyYXRpb24=
-
RGVzaWduZWQgZm9yIGhhcnNoIGVudmlyb25tZW50cw==
-
RWFzaWVyIHRvIGluc3RhbGw=
-
TW9kdWxhciBzb2x1dGlvbiBmb3IgZmxleGlibGUgY29uZmlndXJhdGlvbg==
RnVuY3Rpb24=
Certificates and Declaration
| Conformity to standard #1 | UL98B |
|---|---|
| Conformity to standard #2 | IEC 60947-3 |
| Proposition 65 California | WARNING This product can expose you to chemicals including Styrene, which is known to the State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov |
Environmental Sustainability
| PEP Filename | SOCO-00067-V01.02-EN.pdf |
|---|---|
| Climate change - Total - Cradle to Grave [kg CO₂ eq.] | 474 |
| Climate change - Total - Cradle to Gate [kg CO₂ eq.] | 44 |
Certificates and Declaration - Safety
| UL file number | E346418 |
|---|
Technical Characteristics
| Control operator | Direct : E3 / External : S2L |
|---|---|
| Number of poles | 2//2 |
| Rated voltage | 1500 |
| Rated current [A] | 1000 |
| Type | Frontal operation |
| Frame size | F3 |
Technical Characteristics - Connection terminals
| Max. connection section / AWG | 4x600MCM |
|---|---|
| Min. connection section / AWG | 4x#2 |
Technical Characteristics - Environmental
| Operating temperature | -4 ... +122°F / -20 ... +50°C |
|---|---|
| Storage temperature | -40 ... +158°F / -40 ... +70°C |
Technical Characteristics - Mechanical
| Endurance (number of operating cycles) | 8000 |
|---|
Technical Characteristics - Short-circuit capacity
| Operation voltage 2 P - 3/4 P | 1500VDC |
|---|---|
| Short-circuit capacity at 1000 & 1500 VDC / Prospective short-circuit current [kA rms] | 120 |
| UL General use rating [A] | 1000 |
Logistics
| GTIN/EAN | 3596031107971 |
|---|---|
| Customs number | 8535301090 |
| Price unit | PC |
| Weight of the packing unit [kg] | 6 |
| Length of the packing unit [m] | 0,29 |
| Width of the packing unit [m] | 0,39 |
| Depth of the packing unit [m] | 0,17 |
Product Details
| Effective date | 2022-11-01 |
|---|---|
| Offer Life Cycle Code | 40 |
| Country of origin | TN |
Classification
| UNSPSC | 39122233 |
|---|---|
| ETIM Class | EC000216 |
| IGCC | 5290 |
