U3Ryb25nIFBvaW50cw==

  • UGx1ZyAmIFBsYXk=

  • TXVsdGlmdW5jdGlvbg==

  • Q29ubmVjdGVk

  • Q29tcGFjdA==

RnVuY3Rpb24=

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

Certificates and Declaration

Conformity to standard #1 UL 61010-1 Guide PICQ File E257746
Conformity to standard #2 CSA-C22.2 No. 61010-1
Conformity to standard #3 ISO 14025
Conformity to standard #4 IEC 61557-12
Proposition 65 California WARNING This product can expose you to chemicals including bisphenol A (BPA), which is known to the State of California to cause birth defects or reproductive harm. For more information go to : www.P65Warnings.ca.gov

Environmental Sustainability

Climate change - Total - Cradle to Grave [kg CO₂ eq.] 29
Climate change - Total - Cradle to Gate [kg CO₂ eq.] 11
SVHC > 0.1 mass percentage? No
RoHS applicable? Yes

Standards

Conformity to standards
  • IEC
  • UL

Certificates and Declaration - Safety

UL file number E257746

Technical Characteristics

In/out 4 digital inputs / 2 digital outputs
Model IO-10
Type Digital input module

Technical Characteristics - Environmental

Operating temperature -4 ... +122°F / -20 ... +50°C
Storage temperature -40 ... +158°F / -40 ... +70°C

Technical Characteristics - Measurement

Number of Digital inputs/outputs 4 inputs/ 2 outputs

ETIM - Technical features

Type of accessory/spare part Other
Accessory No
Spare part No

Logistics

GTIN/EAN 3596032912932
Customs number 9030900000
Price unit PC
Weight of the packing unit [kg] 0.09
Length of the packing unit [m] 0.03
Width of the packing unit [m] 0.08
Depth of the packing unit [m] 0.12

Product Details

Effective date 2017-06-01
Offer Life Cycle Code 40
Country of origin FR

Classification

UNSPSC 83101808
ETIM Class EC002295
IGCC 6042

Documentation

Visit resource center
  • Product firmware ZXX
    DIRIS Digiware IO-10 - In_Out module - Version 1.4
    Ask
  • Tender specification EN
    DIRIS Digiware AC Multi-circuit power and residual current monitoring system for electrical installations
    Ask
  • PDF
    Technical note EN-US
    994.98 KB
    How to read measurement data via Modbus on Socomec’s Digiware metering system
    Download
    Select
  • PDF
    Catalog pages EN-US
    1.69 MB
    DIRIS Digiware IO - Digital and analog input_output modules
    Download
    Select
  • PDF
    Selection guide EN-US
    6.62 MB
    Selection Guide - UL_CSA Power Monitoring
    Download
    Select
  • PDF
    Quick start guide EN-US
    178.84 KB
    California Proposition 65 Warning Metering, Monitoring, Power Quality
    Download
    Select
  • PDF
    Brochure EN-US
    7.97 MB
    DIRIS Digiware - Power metering and monitoring system
    Download
    Select
  • PDF
    Technical note EN
    13.12 MB
    DIRIS Digiware communication architectures - Technical Note
    Download
    Select
  • Mechanical view EN-US
    DIRIS Digiware IO-10 4DI/2DO CAD 48290140
    Ask
  • HTML
    Communication table EN
    246.78 KB
    DIRIS Digiware IO-10 1.3.4
    Download
    Select
  • PDF
    Quick start guide EN
    2.58 MB
    DIRIS Digiware IO Inputs / Outputs module for DIRIS Digiware system
    Download
    Select
  • PDF
    Quick start guide EN-US
    2.58 MB
    DIRIS Digiware IO Inputs / Outputs module for DIRIS Digiware system
    Download
    Select

References

DIRIS Digiware IO is also available in 1 version

Item Model Type In/out Select
48290145 IO-20 Analogue input module 2 analogue inputs
