Certificates and Declaration
| Conformity to standard #1 | UL 61010-1 Guide PICQ File E257746 |
|---|---|
| Conformity to standard #2 | CSA-C22.2 No. 61010-1 |
| Conformity to standard #3 | IEC 61557-12 |
| Conformity to standard #4 | ISO 14025 |
| Proposition 65 California | WARNING This product can expose you to chemicals including bisphenol A (BPA), which is known to the State of California to cause birth defects or reproductive harm. For more information go to : www.P65Warnings.ca.gov |
Environmental Sustainability
| Climate change - Total - Cradle to Grave [kg CO₂ eq.] | 114 |
|---|---|
| Climate change - Total - Cradle to Gate [kg CO₂ eq.] | 12 |
| SVHC > 0.1 mass percentage? | No |
| RoHS applicable? | Yes |
Standards
| Conformity to standards |
|
|---|
Certificates and Declaration - Safety
| Safety standards |
IEC/EN 61010-1 UL 61010-1 CAN/CSA C22.2 No. 61010-1 |
|---|---|
| UL file number | E257746 |
General Product Characteristics
| Device type | Display and system interface |
|---|
Technical Characteristics
| Height [mm] | 96 |
|---|---|
| Width [mm] | 18 |
| Depth [mm] | 27 |
| Communication ports | RS485 - Ethernet - Digiware - USB |
| Communication protocols | Modbus RTU - Modbus TCP - SNMP v1, v2, v3 & Traps - BACnet IP - HTTP(S) - FTP(S) - SMTP(S) |
| Model | D-50 |
| Size | 96x96 mm |
| Type | Display and gateway interface for DIRIS Digiware system |
Technical Characteristics - Environmental
| Maximum operating altitude | 6560 feet / 2000 m |
|---|---|
| Operating temperature | +14 to +131°F / -10 to +55°C |
| Relative humidity | 95% at 104°F / 40°C |
| Storage temperature | -4 to +158 °F / -20 to +70°C |
Technical Characteristics - Measurement
| Degree of Pollution | 2 |
|---|
ETIM - Electrical characteristics
| Supply voltage DC [V] | 0..24 |
|---|---|
| Voltage type (supply voltage) | DC |
ETIM - Mechanical characteristics
| Colour display | No |
|---|---|
| Number of colours of the display | 2 |
| Rail mounting possible | Yes |
| Wall mounting/direct mounting | Yes |
| Front built-in possible | Yes |
| Rack-assembly possible | No |
| Degree of protection (IP), front side | IP65 |
| Width of the front [mm] | 18 |
| Height of the front [mm] | 96 |
| Built-in depth [mm] | 27 |
| Operating temperature [°C] | -10..70 |
ETIM - Technical features
| Type of display | LCD |
|---|---|
| Number of grey-scales/blue-scales of display | 10 |
| Screen diagonal [inch] | 3.54 |
| Number of pixels, horizontal | 350 |
| Number of pixels, vertical | 160 |
| Integrated keyboard | Yes |
| With touch screen | No |
| Mouse-cursor control integrated | No |
| With HW-interface PS2 | No |
| Suitable for safety functions | No |
Logistics
| GTIN/EAN | 3596033042010 |
|---|---|
| Customs number | 8528590090 |
| Price unit | PC |
| Weight of the packing unit [kg] | 0.28 |
| Length of the packing unit [m] | 0.09 |
| Width of the packing unit [m] | 0.107 |
| Depth of the packing unit [m] | 0.118 |
Product Details
| Effective date | 2019-03-01 |
|---|---|
| Offer Life Cycle Code | 40 |
| Country of origin | FR |
Classification
| UNSPSC | 83101808 |
|---|---|
| ETIM Class | EC004862 |
| IGCC | 6042 |
Documentation
References
DIRIS Digiware D is also available in 1 version
| Item | Type | Model | Size | Communication protocols | Communication ports | Select |
|---|---|---|---|---|---|---|
| 48290203 | Display and gateway interface for DIRIS Digiware system | D-70 | 96x96 mm | Modbus RTU - Modbus TCP - SNMP v1, v2, v3 & Traps - BACnet IP - HTTP(S) - FTP(S) - SMTP(S) | RS485 - Ethernet - Digiware - USB |
