U3Ryb25nIFBvaW50cw==

  • Um9idXN0LCByZWxpYWJsZSBhbmQgaGlnaCBwZXJmb3JtaW5n

  • U2FmZSBtYW51YWwgaGFuZGxl

  • SW50dWl0aXZlIHVzZSBhbmQgc2ltcGxlIGluc3RhbGxhdGlvbg==

  • SW5zcGVjdGFibGUgY29udGFjdHM=

  • Q29tbXVuaWNhdGVzIHdpdGggb3RoZXIgcHJvZHVjdHM=

  • SW5jbHVkZXMgdGhlIEFUeVMgQzY2IGNvbnRyb2xsZXI=

RnVuY3Rpb24=

QVR5UyBGVCBpcyBhIGZ1bGx5IGF1dG9tYXRpYyBvcGVuIHRyYW5zaXRpb24gdHJhbnNmZXIgc3dpdGNoIGZvciB1c2UgaW4gZW1lcmdlbmN5IHN5c3RlbXMsIGxlZ2FsbHkgcmVxdWlyZWQgc3RhbmRieSBzeXN0ZW1zLCBhbmQgb3B0aW9uYWwgc3RhbmRieSBzeXN0ZW1zIGZvciB0aGUgc2FmZSB0cmFuc2ZlciBiZXR3ZWVuIGEgbm9ybWFsIGFuZCBhbiBhbHRlcm5hdGUgcG93ZXIgc291cmNlLiBBVHlTIEZUIGlzIGEgZmFzdCB0cmFuc2ZlciBzd2l0Y2ggd2l0aCBubyBjZW50ZXItb2ZmIHBvc2l0aW9uLg==

Certificates and Declaration

Conformity to standard #1 cULus 1008

Standards

Conformity to standards UL

Technical Characteristics

Control operator ATSE
Number of poles 3 P
Rated current [A] 260
Frame size F2

Technical Characteristics - Environmental

Operating temperature -4 ... +122°F / -20 ... +50°C
Storage temperature -40 ... +158°F / -40 ... +70°C

Logistics

GTIN/EAN 3596033181948
Customs number 8537109199
Price unit PC

Product Details

Effective date 2020-12-14
Offer Life Cycle Code 40
Country of origin FR

Classification

UNSPSC 39122205
ETIM Class EC000216
IGCC 5177

Documentation

Visit resource center
  • PDF
    Quick start guide EN
    441.87 KB
    ATYS FT DT Connector Kit
    Download
    Select

References

ATyS FT is available in 23 versions

Item Conformity to standard #1 Rated current [A] Number of poles Frame size Control operator Select
96A04010 cULus 1008 100 4 P F1 ATSE
96A04020 cULus 1008 200 4 P F1 ATSE
96A04026 cULus 1008 260 4 P F2 ATSE
96A04040 cULus 1008 400 4 P F2 ATSE
96A12010 cULus 1008 100 2 P+SN F1 ATSE
96A12020 cULus 1008 200 A 2 P+SN F1 ATSE
96A12040 cULus 1008 400 2 P+SN F2 ATSE
96A13010 cULus 1008 100 3 P+SN F1 ATSE
96A13020 cULus 1008 200 3 P+SN F1 ATSE
96A13026 cULus 1008 260 3 P+SN F2 ATSE
96A13040 cULus 1008 400 3 P+SN F2 ATSE
96803010 cULus 1008 100 3 P F1 ATSE
96803020 cULus 1008 200 3 P F1 ATSE
96803040 cULus 1008 400 3 P F2 ATSE
96A02010 cULus 1008 100 2 P F1 ATSE
96A02020 cULus 1008 200 2 P F1 ATSE
96A02026 cULus 1008 260 2 P F2 ATSE
96A02040 cULus 1008 400 2 P F2 ATSE
96A03010 cULus 1008 100 3 P F1 ATSE
96A03020 cULus 1008 200 3 P F1 ATSE
96A03026 cULus 1008 260 3 P F2 ATSE
96A03040 cULus 1008 400 3 P F2 ATSE
96A12026 cULus 1008 260 2 P+SN F2 ATSE
