Certificates and Declaration
Conformity to standard #1 | cULus 1008 |
---|---|
Conformity to standard #2 | CSA-C22.2 No. 178.1-14 |
Proposition 65 California | WARNING This product can expose you to chemicals including styrene and bisphenol A, which is known to the State of California to cause cancer and birth defects or reproductive harm. For more information go to : www.P65Warnings.ca.gov |
Certificates and Declaration - Safety
UL file number | E506172 |
---|
Technical Characteristics
Control operator | ATSE |
---|---|
Number of poles | 4 P |
Rated current [A] | 400 |
Frame size | F2 |
Technical Characteristics - Connection terminals
Max. connection section / AWG | 600 KCMIL |
---|---|
Min. connection section / AWG | #4 |
Technical Characteristics - Environmental
Operating temperature | -4 ... +122°F / -20 ... +50°C |
---|---|
Storage temperature | -40 ... +158°F / -40 ... +70°C |
Technical Characteristics - Mechanical
Endurance (number of operating cycles) | 6050 |
---|
Technical Characteristics - Power supply
Power supply / Supply voltage VAC 50/60 Hz | 194-304 |
---|
Technical Characteristics - Short-circuit capacity
Max fuse rating [A] | 600 |
---|---|
Operation voltage 2 P - 3/4 P | 120V - 480V |
Rated operational current / 480 VAC “Total System” [A] | 400 |
Type of fuse | J |
Logistics
GTIN/EAN | 3596033115097 |
---|---|
Customs number | 8537109199 |
Product Details
Effective date | 2019-10-07 |
---|---|
Offer Life Cycle Code | 40 |
Country of origin | FR |
Classification
UNSPSC | 39122205 |
---|---|
ETIM Class | EC000216 |
IGCC | 5177 |
