U3Ryb25nIFBvaW50cw==

  • U3RhYmxlIHBvc2l0aW9ucw==

  • Q29tcGFjdCBkZXNpZ24=

  • T24tbG9hZCBzd2l0Y2hpbmc=

  • UmVsaWFiaWxpdHk=

RnVuY3Rpb24=

U0lSQ09WRVIgYXJlIGhlYXZ5LWR1dHkgbWFudWFsIHRyYW5zZmVyIHN3aXRjaGVzLiBUaGV5IGVuc3VyZSBzd2l0Y2hpbmcgdHJhbnNmZXIgb2Ygc291cmNlcyBvciB0cmFuc2ZlciBvZiB0d28gbG93IHZvbHRhZ2UgY2lyY3VpdHMgb24gbG9hZCBhcyB3ZWxsIGFzIHRoZWlyIHNhZmUgZGlzY29ubmVjdGlvbi48YnIgLz4NClRoZXNlIGV4dHJlbWVseSBkdXJhYmxlwqBzd2l0Y2hlcyBhcmUgdGVzdGVkIGFuZCBhcHByb3ZlZCBmb3IgdXNlIGluIHRoZSBtb3N0IGRlbWFuZGluZyBhcHBsaWNhdGlvbnMsIHN1Y2ggYXMgcmVzaXN0aXZlIGxvYWQgb3IgdG90YWwgc3lzdGVtIGFwcGxpY2F0aW9ucy4=

Certificates and Declaration

Conformity to standard #1 UL 1008
Proposition 65 California WARNING This product can expose you to chemicals including Styrene, which is known to the State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov

Environmental Sustainability

Climate change - Total - Cradle to Grave [kg CO₂ eq.] 82
Climate change - Total - Cradle to Gate [kg CO₂ eq.] 46
SVHC > 0.1 mass percentage? No
RoHS applicable? Yes

Standards

Conformity to standards UL

Technical Characteristics

Weight [kg] 5.38
Control operator MTSE
Number of poles 3
Rated current [A] 200

ETIM - Electrical characteristics

Max. rated operation voltage Ue AC [V] 600
Rated operating voltage [V] 240..600
Rated permanent current Iu [A] 200
Number of poles 3

ETIM - Mechanical characteristics

Suitable for floor mounting No
Suitable for front mounting 4-hole No
Suitable for front mounting centre No
Suitable for distribution board installation No
Suitable for intermediate mounting Yes
Colour control element Black
Degree of protection (IP), front side IP20

ETIM - Technical features

Version as main switch Yes
Version as maintenance-/service switch Yes
Version as safety switch Yes
Version as emergency stop installation No
Version as reversing switch Yes
Number of switches 2
Motor drive optional No
Motor drive integrated No
Voltage release optional No
Device construction Built-in device fixed built-in technique
Type of control element Door coupling rotary drive
Interlockable Yes
Type of electrical connection of main circuit Bolt connection

Logistics

GTIN/EAN 3596031982004
Customs number 8536508000
Price unit PC
Weight of the packing unit [kg] 5.38
Length of the packing unit [m] 0.266
Width of the packing unit [m] 0.378
Depth of the packing unit [m] 0.381

Product Details

Effective date 2009-11-10
Offer Life Cycle Code 40
Country of origin FR

Classification

UNSPSC 39122205
ETIM Class EC000216
IGCC 5177

Documentation

Visit resource center
  • PDF
    Catalogue - extract EN-US
    5.57 MB
    Solutions for Transfer Switching
    Download
    Select
  • PDF
    Catalog pages EN-US
    2.66 MB
    SIRCOVER UL 98_1008 - Manually operated transfer switching equipment
    Download
    Select
  • PDF
    Quick start guide EN-US
    178.21 KB
    California Proposition 65 Warning SIRCOVER
    Download
    Select
  • Mechanical view EN-US
    SIRCOVER UL 3X200A F CAD 41503021
    Ask

References

SIRCOVER UL is also available in 23 versions

Item Conformity to standard #1 Rated current [A] Number of poles Control operator Select
41503026 UL 1008 260 3 MTSE
41504026 UL 1008 260 4 MTSE
41502012 UL 1008 100 2 MTSE
41503012 UL1008 100 3 MTSE
41504012 UL1008 100 4 MTSE
41502022 UL 1008 200 2 MTSE
41503022 UL1008 200 3 MTSE
41504022 UL1008 200 4 MTSE
41502026 UL 1008 260 2 MTSE
41502042 UL 1008 400 2 MTSE
41503042 UL1008 400 3 MTSE
41504042 UL1008 400 4 MTSE
41503011 UL 1008 100 3 MTSE
41503060 UL1008 & UL98 600 3 MTSE
41504011 UL 1008 100 4 MTSE
41504060 UL1008 & UL98 600 4 MTSE
41503080 UL1008 & UL98 800 3 MTSE
41504021 UL 1008 200 4 MTSE
41504080 UL1008 & UL98 800 4 MTSE
41503041 UL 1008 400 3 MTSE
41503120 UL1008 & UL98 1200 3 MTSE
41504041 UL 1008 400 4 MTSE
41504120 UL1008 & UL98 1200 4 MTSE
