Environmental Sustainability
| PEP Filename | SOCO-00055-V01.01-EN.pdf |
|---|---|
| Climate change - Total - Cradle to Grave [kg CO₂ eq.] | 377 |
| Climate change - Total - Cradle to Gate [kg CO₂ eq.] | 41 |
Technical Characteristics
| Length of the product unit [mm] | 98.5 |
|---|---|
| Width of the product unit [mm] | 98.5 |
| Depth of the product unit [mm] | 108 |
| Weight [kg] | 0.349 |
| Application | Analysis |
| Communication ports | RS485 + Dual Ethernet |
| Communication protocols | Modbus RTU; Modbus TCP; BACnet IP |
| Model | A-200 |
| Type | RJ12 |
ETIM - Electrical characteristics
| Accuracy class active energy according to IEC 62053-22 | 0.1S |
|---|---|
| Accuracy class reactive energy according to IEC 62053-23 | Other |
| Pulse output | Electrical |
| Sampling frequency [Hz] | 9600 |
| Number of voltage measurement inputs | 4 |
| Number of current measurement inputs | 4 |
| Voltage type (supply voltage) | AC |
| Supply voltage AC 50 Hz [V] | 115..600 |
| Supply voltage AC 60 Hz [V] | 115..600 |
| Measuring range for frequency [Hz] | 50..60 |
| Max. current (Imax) [A] | 10000 |
| Display resolution (horizontal) [px] | 350 |
| Display resolution (vertical) [px] | 160 |
| Number of digital inputs | 3 |
| Number of digital outputs | 1 |
| Number of Ethernet-connections | 2 |
| Suitable for RJ plug | Yes |
| Supporting protocol for IEC 61850 Ethernet | No |
| Supporting protocol for OPC UA PubSub | No |
| Supporting protocol for PROFIBUS | No |
| Supporting protocol for Modbus | Yes |
| Supporting protocol for PROFINET IO | No |
| Supporting protocol for other bus systems | Yes |
| With firmware signature | Yes |
| With logging of security events (security event log) | Yes |
| Web server with HTTPS transfer protocol | Yes |
ETIM - Mechanical characteristics
| Mounting method | Front mounting |
|---|---|
| Width [mm] | 98.5 |
| Height [mm] | 98.5 |
| Depth [mm] | 108 |
| Degree of protection (IP), front side | Other |
ETIM - Technical features
| Display | Graphic |
|---|---|
| Remote display | No |
| With communication interface KNX | No |
| Wth communication interface M-Bus | No |
| With communication interface RS-485 | Yes |
Logistics
| GTIN/EAN | 3596033205484 |
|---|---|
| Customs number | 9030320000 |
| Weight of the packing unit [kg] | 0,44 |
| Length of the packing unit [m] | 0,135 |
| Width of the packing unit [m] | 0,12 |
| Depth of the packing unit [m] | 0,11 |
Product Details
| Effective date | 2023-06-01 |
|---|---|
| Offer Life Cycle Code | 40 |
| Country of origin | US |
Classification
| UNSPSC | 83101808 |
|---|---|
| ETIM Class | EC002301 |
