Function
The DIRIS Digiware BCM is a multi-circuit metering module with 21 integrated sensors and allows individual circuit monitoring within any electrical panelboard (Remote Power Panel, lighting panel, power panel etc.). The DIRIS Digiware BCM is also equipped with three RJ12 channels connected to TE/TR/iTR/TF current sensors and ΔIC zero sequence CTs.
=-=-=-=-=-=- System =-=-=-=-=-=-
Fill rate E-Order Selection | 25 |
---|
Certificates and Declaration
Conformity to standard #1 | UL 61010 Guide FTRZ/PICQ File E257746 |
---|---|
Conformity to standard #2 | ANSI C12.20 |
Conformity to standard #3 | IEC 61557-12 |
Proposition 65 California | WARNING This product can expose you to chemicals including bisphenol A (BPA), which is known to the State of California to cause birth defects or reproductive harm. For more information go to : www.P65Warnings.ca.gov |
Certificates and Declaration - Safety
UL file number | E257746 |
---|
Technical Characteristics
Model | BCM-2119 |
---|---|
Number of current inputs | 21 + 3x RJ12 |
Type | Without Breaker Status |
Technical Characteristics - Environmental
Maximum operating altitude | 6560 feet / 2000 m |
---|---|
Operating temperature | +14 ... +131°F / -10 ... +55°C |
Relative humidity | 40°C / 95% RH |
Storage temperature | -40 ... +158°F / -40 ... +70°C |
Technical Characteristics - Measurement
Accuracy class | Class 0.5 |
---|---|
Current measurement type | AC |
Current rating range | 32 … 63 A |
Current sensor type | Solid Core |
General measurements | Metering:+/- kWh, +/- kvarh, kVAhMulti-measurement: I1, I2, I3, In, ∑P, ∑Q, ∑S, ∑PF, P,Q,S,pf PER PHASE, Predictive Power, Current Unbalance, Phi, cos Phi, tan Phi |
Power Quality measurements | Power Quality: THDi1, THDi2, THDi3,THDin, THD Isys, Individual harmonics I (up to 63rd),Crest Factor I1, I2, I3, Overcurrent |
Logistics
GTIN/EAN | 3596033199813 |
---|---|
Customs number | 9030337000 |
Product Details
Effective date | 2022-11-01 |
---|---|
Country of origin | TN |
Discount Policy | 1EN20 |
Discount Policy Label | ELECTRONIC SENSORS |
