=-=-=-=-=-=- System =-=-=-=-=-=-
| Fill rate E-Order Selection | 25 |
|---|
Certificates and Declaration
| Conformity to standard #1 | UL 61010 Guide FTRZ/PICQ File E257746 |
|---|---|
| Conformity to standard #2 | ANSI C12.20 |
| Conformity to standard #3 | IEC 61557-12 |
| Proposition 65 California | WARNING This product can expose you to chemicals including bisphenol A (BPA), which is known to the State of California to cause birth defects or reproductive harm. For more information go to : www.P65Warnings.ca.gov |
Certificates and Declaration - Safety
| UL file number | E257746 |
|---|
Technical Characteristics
| Model | BCM-2125VM |
|---|---|
| Number of current inputs | 21 + 3x RJ12 |
| Type | With Breaker Status |
Technical Characteristics - Environmental
| Maximum operating altitude | 6560 feet / 2000 m |
|---|---|
| Operating temperature | +14 ... +131°F / -10 ... +55°C |
| Relative humidity | 40°C / 95% RH |
| Storage temperature | -40 ... +158°F / -40 ... +70°C |
Technical Characteristics - Measurement
| Accuracy class | Class 0.5 |
|---|---|
| Current measurement type | AC |
| Current rating range | 40 … 100 A |
| Current sensor type | Solid Core |
| General measurements | Metering:+/- kWh, +/- kvarh, kVAhMulti-measurement: I1, I2, I3, In, ∑P, ∑Q, ∑S, ∑PF, P,Q,S,pf PER PHASE, Predictive Power, Current Unbalance, Phi, cos Phi, tan Phi |
| Power Quality measurements | Power Quality: THDi1, THDi2, THDi3,THDin, THD Isys, Individual harmonics I (up to 63rd),Crest Factor I1, I2, I3, Overcurrent |
Logistics
| GTIN/EAN | 3596033199844 |
|---|---|
| Customs number | 9030337000 |
Product Details
| Effective date | 2022-11-01 |
|---|---|
| Country of origin | TN |
| Discount Policy | 1EN20 |
| Discount Policy Label | ELECTRONIC SENSORS |
