Function

The DIRIS Digiware BCM is a multi-circuit metering module with 21 integrated sensors and allows individual circuit monitoring within any electrical panelboard (Remote Power Panel, lighting panel, power panel etc.). The DIRIS Digiware BCM is also equipped with three RJ12 channels connected to TE/TR/iTR/TF current sensors and ΔIC zero sequence CTs.

=-=-=-=-=-=- System =-=-=-=-=-=-
Fill rate E-Order Selection 25
Certificates and Declaration
Conformity to standard #1 UL 61010 Guide FTRZ/PICQ File E257746
Conformity to standard #2 ANSI C12.20
Conformity to standard #3 IEC 61557-12
Proposition 65 California WARNING This product can expose you to chemicals including bisphenol A (BPA), which is known to the State of California to cause birth defects or reproductive harm. For more information go to : www.P65Warnings.ca.gov
Certificates and Declaration - Safety
UL file number E257746
Technical Characteristics
Model BCM-2119VM
Number of current inputs 21 + 3x RJ12
Type With Breaker Status
Technical Characteristics - Environmental
Maximum operating altitude 6560 feet / 2000 m
Operating temperature +14 ... +131°F / -10 ... +55°C
Relative humidity 40°C / 95% RH
Storage temperature -40 ... +158°F / -40 ... +70°C
Technical Characteristics - Measurement
Accuracy class Class 0.5
Current measurement type AC
Current rating range 32 … 63 A
Current sensor type Solid Core
General measurements Metering:+/- kWh, +/- kvarh, kVAhMulti-measurement: I1, I2, I3, In, ∑P, ∑Q, ∑S, ∑PF, P,Q,S,pf PER PHASE, Predictive Power, Current Unbalance, Phi, cos Phi, tan Phi
Power Quality measurements Power Quality: THDi1, THDi2, THDi3,THDin, THD Isys, Individual harmonics I (up to 63rd),Crest Factor I1, I2, I3, Overcurrent
Logistics
GTIN/EAN 3596033199820
Customs number 9030337000
Product Details
Effective date 2022-11-01
Country of origin TN
Discount Policy 1EN20
Discount Policy Label ELECTRONIC SENSORS
