U3Ryb25nIFBvaW50cw==

  • M3ggcXVpY2tlciB0byBpbnN0YWxsIHRoYW4gc3RhbmRhcmQgc29sdXRpb25z

  • MnggcXVpY2tlciB0byBjb25maWd1cmUgdGhhbiBzdGFuZGFyZCBzb2x1dGlvbnM=

  • TWluaW1hbCBmb290cHJpbnQ=

  • TWF4aW11bSByZWxpYWJpbGl0eQ==

  • QnJlYWtlciBzdGF0dXM=

  • VW5yaXZhbGVkIGFjY3VyYWN5

RnVuY3Rpb24=

VGhlIERJUklTIERpZ2l3YXJlIEJDTSBpcyBhIG11bHRpLWNpcmN1aXQgbWV0ZXJpbmcgbW9kdWxlIHdpdGggMjEgaW50ZWdyYXRlZCBzZW5zb3JzIGFuZMKgYWxsb3dzIGluZGl2aWR1YWwgY2lyY3VpdCBtb25pdG9yaW5nIHdpdGhpbiBhbnkgZWxlY3RyaWNhbCBwYW5lbGJvYXJkIChSZW1vdGUgUG93ZXIgUGFuZWwswqBsaWdodGluZyBwYW5lbCwgcG93ZXIgcGFuZWwgZXRjLikuIFRoZSBESVJJUyBEaWdpd2FyZSBCQ00gaXMgYWxzbyBlcXVpcHBlZCB3aXRoIHRocmVlIFJKMTLCoGNoYW5uZWxzIGNvbm5lY3RlZCB0byBURS9UUi9pVFIvVEYgY3VycmVudCBzZW5zb3JzIGFuZCDOlElDIHplcm8gc2VxdWVuY2UgQ1RzLg==

Certificates and Declaration

Conformity to standard #1 UL 61010 Guide FTRZ/PICQ File E257746
Conformity to standard #2 ANSI C12.20
Conformity to standard #3 IEC 61557-12
Proposition 65 California WARNING This product can expose you to chemicals including bisphenol A (BPA), which is known to the State of California to cause birth defects or reproductive harm. For more information go to : www.P65Warnings.ca.gov

Environmental Sustainability

Climate change - Total - Cradle to Grave [kg CO₂ eq.] 103
Climate change - Total - Cradle to Gate [kg CO₂ eq.] 26
SVHC > 0.1 mass percentage? No
RoHS applicable? Yes

Certificates and Declaration - Safety

UL file number E257746

Technical Characteristics

Model BCM-2125
Number of current inputs 21 + 3x RJ12
Type Without Breaker Status

Technical Characteristics - Environmental

Maximum operating altitude 6560 feet / 2000 m
Operating temperature +14 ... +131°F / -10 ... +55°C
Relative humidity 40°C / 95% RH
Storage temperature -40 ... +158°F / -40 ... +70°C

Technical Characteristics - Measurement

Accuracy class Class 0.5
Current measurement type AC
Current rating range 40 … 100 A
Current sensor type Solid Core
General measurements Metering:+/- kWh, +/- kvarh, kVAhMulti-measurement: I1, I2, I3, In, ∑P, ∑Q, ∑S, ∑PF, P,Q,S,pf PER PHASE, Predictive Power, Current Unbalance, Phi, cos Phi, tan Phi
Power Quality measurements Power Quality: THDi1, THDi2, THDi3,THDin, THD Isys, Individual harmonics I (up to 63rd),Crest Factor I1, I2, I3, Overcurrent
Pitch 1in (25mm)
Maximum Current [A] 120

Logistics

GTIN/EAN 3596033199837
Customs number 9030337000
Price unit PC
Weight of the packing unit [kg] 2

Product Details

Effective date 2022-11-01
Offer Life Cycle Code 40
Country of origin TN

Classification

UNSPSC 83101808
ETIM Class EC002301
IGCC 6042

Documentation

Visit resource center
  • Product firmware ZXX
    DIRIS Digiware BCM-2125 - Version 1.3
    Ask
  • PDF
    Declaration of conformity EN-US
    213.71 KB
    DIRIS Digiware BCM_FCC declaration
    Download
    Select
  • PDF
    Installation and operating manual EN-US
    3.03 MB
    INSTRUCTION MANUAL - DIRIS Digiware BCM with D-70_Comissioning-Guide
    Download
    Select
  • PDF
    Technical note EN-US
    994.98 KB
    How to read measurement data via Modbus on Socomec’s Digiware metering system
    Download
    Select
  • PDF
    Catalog pages EN-US
    2.24 MB
    DIRIS Digiware BCM - Branch-circuit monitoring module with integrated current sensors
    Download
    Select
  • PDF
    Catalog pages EN-US
    840.42 KB
    TF Sensors - Flexible TF current sensors
    Download
    Select
  • PDF
    Selection guide EN-US
    6.62 MB
    Selection Guide - UL_CSA Power Monitoring
    Download
    Select
  • PDF
    Brochure EN-US
    7.97 MB
    DIRIS Digiware - Power metering and monitoring system
    Download
    Select
  • Mechanical view EN-US
    DIRIS DIGIWARE BCM-2125 120A CAD 48290169
    Ask
  • PDF
    Brochure EN-US
    9.24 MB
    DIRIS DIGIWARE SBCM
    Download
    Select
  • HTML
    Communication table EN
    11.32 MB
    DIRIS Digiware BCM-2125 HTML CONFIG
    Download
    Select
  • HTML
    Communication table EN
    12.12 MB
    DIRIS Digiware BCM-2125VM HTML CONFIG
    Download
    Select
  • PDF
    Installation and operating manual EN-US
    3.36 MB
    INSTRUCTION MANUAL - DIRIS Digiware SBCM with D-70_Comissioning Guide
    Download
    Select
  • HTML
    Communication table EN
    8.37 MB
    DIRIS Digiware BCM-2125 HTML CLIENT
    Download
    Select
  • HTML
    Communication table EN
    8.53 MB
    DIRIS Digiware BCM-2125VM HTML CLIENT
    Download
    Select
  • HTML
    Communication table EN
    12.12 MB
    DIRIS Digiware BCM-2119VM HTML CONFIG
    Download
    Select
  • HTML
    Communication table EN
    8.37 MB
    DIRIS Digiware BCM-2119 HTML CLIENT
    Download
    Select
  • HTML
    Communication table EN
    11.32 MB
    DIRIS Digiware BCM-2119 HTML CONFIG
    Download
    Select
  • HTML
    Communication table EN
    8.53 MB
    DIRIS Digiware BCM-2119VM HTML CLIENT
    Download
    Select
  • PDF
    Quick start guide EN
    2.36 MB
    DIRIS Digiware BCM-21xx
    Download
    Select

References

DIRIS Digiware BCM is also available in 3 versions

Item Model Pitch Type Maximum Current [A] Number of current inputs Select
48290167 BCM-2119 3/4in (19mm) Without Breaker Status 80 21 + 3x RJ12
48290168 BCM-2119VM 3/4in (19mm) With Breaker Status 80 21 + 3x RJ12
48290170 BCM-2125VM 1in (25mm) With Breaker Status 120 21 + 3x RJ12
